| 貨號 | 材質Material | 球體 Ball |
| Z133 | 合金剛 ST | 合金剛 ST |
| Z134 | 不銹鋼 SUS | 不銹鋼 SUS |
產品規格
| 貨 號 | D | L | d | L1 | B | 荷重N |
| Z133(鐵) Z134(不銹鋼) |
M3 | 5.2 10.2 | 1.5 | 0.5 | 1.5 | 0.5 |
| M4 | 6.5 10.5 16.5 | 2.5 | 0.8 | 2 | 1.3 | |
| M5 | 8.6 12.6 20.6 | 3 | 1 | 2.5 | 1.4 | |
| M6 | 10.8 16.8 20.8 25.8 | 4 | 1.3 | 3 | 3.3 | |
| M8 | 11.2 13.2 21.2 26.2 31.2 | 5.6 | 1.8 | 4 | 3.9 | |
| M10 | 13.7 17.7 21.7 26.7 36.7 | 7.1 | 2.3 | 5 | 3.4 | |
| M12 | 18 22 32 42 | 8.7 | 2.8 | 6 | 4.8 | |
| M16 | 23.3 38.3 53.3 | 11.9 | 4.3 | 8 | 8.9 |
